MADRE CR – HARD TAIL – GRAVEL/FARGO – 700B/29″/650B+ WHEELS

Price
  • Our frames are made by hand one by one in our workshop. We can do them tailor made and we can offer many customization.
  • Delivery within 60 days from order confirmation. (General description of the service and Shipping cost)
  • Overview
      • TYPE:FARGO – BIKEPACKING / OFF-ROAD TOURING / SINGLETRACK
      • WHEELS SIZE:27.5″ or 29″ or 605b+
      • FRAME MATERIAL:COLUMBUS NIVACROM
      • SYSTEM: Hard tail
      • BB: 73mm BSA Threaded
      • DROPOUTS: Slide 10mm: 135×10 QR or 142x12mm or 148x12mm
      • WEIGHT: 2.10Kg (SIZE M)
      • SIZE: S, M, L, XL or Tailor made
    Geometry
    Slider_16_geo
    SIZE ST TTR TT SO REACH STACK SA HA HT CS BH WB RIDER HT
    S 390 550 548 687 367 618 73.5° 69° 110 445-455 300 1072 150-165cm
    M 450 575 559 739 388 632 73.5° 69° 125 445-455 300 1098 165-175cm
    L 510 600 579 794 406 655 73.5° 69° 150 445-455 300 1125 175-185cm
    XL 560 625 601 838 424 679 73.5° 69° 175 445-455 300 1152 185-200cm

    Geometry based on 29×2.1 tires with 485mm fork length (80mm travel)
    BB Drop:70mm
    Due we make this frame only by order, we can do custom geometry without a surcharge

    Frame Specs
    • Max Fork travel: 100mm(29″), 120mm(27.5″)
    • Headset (Top): 44mm Zero Stack
    • Headset (Bottom): 44mm External Cup
    • BB Shell: 73mm BSA Threaded
    • Rear Brake Mount: 160mm Post Mount
    • Rear Axle: 135×10 Qr or 142x12mm or 148x12mm
    • Front Derailleur: 34.9mm top swing, down pull (only on request)
    • Seatpost Diameter: 30.9mm
    • Seat Clamp: 33mm
    • Max Chainring Size:36t Single or 26/38 Double
    • Crankset compatibility:Std or Boost Crankset
    • Max Tire Size: 29″x2.1 or 27.5″x2.5
    Bike Specs

    We can offer whole bike assembly following customer spec. Please contact us by mail info@mdebikes.com in order to get a quotation.
